Description

G-Repository Server is the only GenRocket component installed within your corporate environment that will communicate with GenRocket Cloud.  Its primary tasks are the following:

  • Monitor recent actions performed on GenRocket Cloud  (Inserts, Updates, and Deletions)
  • Mirror recent actions performed on GenRocket Cloud in its local repository
  • Monitor run requests from multiple G-Repository Clients simultaneously
    • Perform user profile checks as a secure proxy for G-Repository Clients
    • Check if G-Repository Client needs updating
    • Send Repository Updates to G-Repository Client
    • Collect G-Repository Client Scenario-run stats
  • Send G-Repository Client Scenario-run stats to GenRocket Cloud



In This Article


G-Repository User Validation

A G-Repository Server can only be set up and launched by a GenRocket Org Admin.  A GenRocket Org Admin must first download their GenRocket profile to the machine, where a G-Repository server is to be set up, and place their profile in the .genrocket subdirectory.  Thus, a GenRocket Org Admin may download their GenRocket profile on multiple machines should they choose to set up multiple G-Repository Servers.

  • Once a G-Repository Server is set up with the given GenRocket Org Admin, it is permanently tied to that Org Admin.
  • The G-Repository server will check that the given Org Admin is a valid, enabled user.
  • The G-Repository server will stay active as long as the Org Admin is a valid GenRocket user.

Note: An Org Admin's Email ID functions as their unique User ID in GenRocket and is used by G-Repository to perform the required validation check.



G-Repository Server Hardware Requirements

G-Repository Server has been designed to run optimally on a Linux Server or Mac (Unix). These are the recommended operating systems. Its minimum suggested requirements are the following:

  • Linux Ubuntu 64 Bit OS
  • Intel or AMD 4Core CPU
  • 16GB RAM
  • 500 GB SSD

Please Note: While Windows operating system can be used, it is not recommended for G-Repository Server. Using this operating system may cause a considerable decrease in performance.


Java Runtime / GenRocket Jar Requirements & Setup

G-Repository Server requires a Java Runtime to run.  Perform the following steps to install Java:

  1. Download and install a supported Java version.
  2. Download and install the latest GenRocket runtime
  3. Login to GenRocket Cloud and create a Server profile
  4. Download and move the Server GenRocket profile into the .genrocket subdirectory

Note: For more detailed installation instructions, see GenRocket Runtime Overview.


G-Repository Server Property Files

Once a G-Repository Server has been created (See How to Set Up a G-Repository Server), it will create a .grepository subdirectory within the subdirectory it was created and, within the .grepository subdirectory, it will create three property files:

  • server.properties
  • grepository.properties


server. properties

The server.properties file contains configuration properties for the different components running on multiple threads within the given G-Repository Server.  This file is unencrypted and may be modified to tune a G-Repository Server for optimal performance. However, it is advisable to speak with a GenRocket support technician before changing any property values. The default property values within the server.properties file are the following:


#
# Server Properties
#
mainServerPort=8020
downloadServerPort=8021
memoryLimit=64
cpuUsage=0.95
updateThreadLimit=10
downloadThreadLimit=10
maxPoolActive=10
maxPoolIdle=5
minPoolIdle=3
copyTimeoutSecs=180
autoUpdateCycleMin=60
autoDeleteCycleSecs=60
autoWaitCopyCycleSecs=60
autoStatsCycleSecs=60


grepository.properties

The grepository.properties file is encrypted and contains information that allows a G-Repository Server to access GenRocket Cloud for a given GenRocket Organization and users of that organization via G-Repository Client.  This property file is managed by the G-Repository Server.
