Overview

To set up the Unstructured Data Accelerator (UDA) and start generating PDFs from a template, a few steps must be completed to properly configure the Runtime environment. This guide walks you through the complete setup process for enabling PDF import functionality in your GenRocket environment. The setup includes configuring the runtime environment, installing required dependencies, and preparing necessary files.

Prerequisites

  • GenRocket Runtime - GenRocket installation directory access (For help, click here)
  • Internet connection for downloading dependencies
  • Administrative privileges (for Node.js installation)


Step 1 - Enable UDA Import from PDF

Ensure UDA Import from PDF is enabled. Contact support@genrocket.com if not.


Step 2 - Download the UDA JAR File

  1. Download the UDA Jar file from the GenRocket web platform under Options > Download UDA Jar.
  2. Place the file in the genrocket/lib directory (location varies by installation).


Step 3 - Download the Node Runtime Package

To learn more about Node.js, please see this web page: Node.js — Introduction to Node.js

  1. Download the Node runtime package from:
    https://gr-groovy.s3.us-east-1.amazonaws.com/uda/node_runtime.zip

  2. Extract the contents to the genrocket/lib folder. The extraction path will vary based on the operating system and where GenRocket Runtime is installed. Common paths include:
    • Windows - C:\Users\<username>\genrocket\lib
    • Mac OSx or Linux - /home/users/<username>/genrocket/lib


Step 4 - Node.js Installation (per Operating System)

To set up Node.js, follow these steps:


1. Node version 20.18.0 is required.

Windows - Using Installer

  1. Download Node.js v20.18.0 installer from: https://nodejs.org/dist/v20.18.0/node-v20.18.0-x64.msi
  2. Run the .msi file and follow the installation wizard. Follow the prompts for installation and use the default values.
  3. Verify installation with the following command:


node --version
npm --version


Linux - Using NVM (Node Version Manager)

Open a terminal window and use the curl command and other commands to download the installer and complete the install:


curl -o- https://raw.githubusercontent.com/nvm-sh/nvm/v0.39.0/install.sh | bash

source ~/.bashrc

nvm install 20.18.0

nvm use 20.18.0


MacOS - Using NVM (Node Version Manager)

Open a terminal window and use the curl command and other commands to download the installer and complete the install:


curl -o- https://raw.githubusercontent.com/nvm-sh/nvm/v0.39.0/install.sh | bash

source ~/.zshrc  # or ~/.bash_profile

nvm install 20.18.0

nvm use 20.18.0



Step 5 - Post-Installation (All OS)

Make sure the command window path points to the node_runtime location (Step 3 above). For local runtime installs, the path will be:

  • Linux/Mac - /home/users/username/genrocket/lib/node_runtime
  • Windows - C:\users\username\genrocket\lib\node_runtime


cd path/to/node_runtime/


Then run the command below:

npm install



Next Steps

After a successful environment setup, you are ready to import a source PDF file, make any needed customizations to the created template, and export the template for Project setup. Click here to learn more.
